LRA042薄壁軸承、LRA042薄壁深溝球軸承、LRA042薄壁角接觸球軸承

軸	基本尺寸			球數	重量	額定負載						極限
承	d	D	B			徑向		推力		傾覆		極限
型	d	D	B			靜	動	靜	動	靜	動	轉速
號	mm	mm	mm	個	Kg	Co(N)	Cr(N)	N	N	Nm	Nm	(RPM)
LRAA10	25.4	34.93	4.763	21	0.014	1,290	1,330	2,140	3,910	10	25	16,840
LRAA15	38.1	47.63	4.763	29	0.018	1,780	1,560	2,890	4,540	25	40	11,850
LRA020	50.8	63.5	6.35	27	0.045	3,020	2,490	4,800	7,300	55	80	8,890
LRB020	50.8	66.68	7.938	23	0.073	4,140	3,560	6,490	10,320	80	120	8,650
LRA025	63.5	76.2	6.35	33	0.059	3,690	2,710	5,830	7,870	80	110	7,270
LRB025	63.5	79.38	7.938	28	0.091	5,070	3,830	7,780	11,170	110	160	7,110
LRA030	76.2	88.9	6.35	39	0.068	4,400	2,890	6,810	8,360	110	140	6,150
LRB030	76.2	92.08	7.938	33	0.109	5,960	4,090	9,120	11,920	150	200	6,040
LRA035	88.9	101.6	6.35	45	0.082	5,070	3,070	7,780	8,850	150	170	5,330
LRB035	88.9	104.8	7.938	38	0.122	6,850	4,310	10,410	12,500	200	240	5,250
LRA040	101.6	114.3	6.35	51	0.086	5,740	3,200	8,810	9,250	190	200	4,710
LRB040	101.6	117.5	7.938	43	0.136	7,780	4,540	11,700	13,120	260	290	4,640
LRC040	101.6	120.7	9.525	35	0.204	9,340	5,740	13,830	16,640	310	370	4,570
LRD040	101.6	127	12.7	27	0.354	13,700	10,010	22,020	29,000	500	660	4,440
LRF040	101.6	139.7	19.05	19	0.862	23,840	17,530	35,500	50,800	860	1,230	4,210
LRG040	101.6	152.4	25.4	15	1.633	36,520	29,800	57,650	86,470	1,460	2,200	4,000
LRA042	108	120.7	6.35	54	0.091	6,090	3,250	9,300	9,390	210	210	4,440
LRB042	108	123.8	7.938	45	0.141	8,140	4,580	12,190	13,340	280	310	4,380
LRC042	108	127	9.525	37	0.213	9,880	5,870	14,550	17,040	340	400	4,320
LRD042	108	133.4	12.7	28	0.376	14,190	10,100	22,730	29,270	550	710	4,210
LRF042	108	146.1	19.05	20	0.907	25,090	18,100	37,370	52,530	950	1,330	4,000
LRG042	108	158.8	25.4	15	1.724	36,520	29,800	57,650	86,470	1,540	2,310	3,810
LRA045	114.3	127	6.35	57	0.1	6,410	3,340	9,790	9,650	240	230	4,210
LRB045	114.3	130.2	7.938	48	0.15	8,670	4,720	12,990	13,700	320	330	4,160
LRC045	114.3	133.4	9.525	39	0.218	10,410	6,010	15,300	17,390	380	430	4,100
LRD045	114.3	139.7	12.7	30	0.399	15,210	10,450	24,290	30,340	620	770	4,000
LRF045	114.3	152.4	19.05	21	0.953	26,380	18,730	39,230	54,270	1,050	1,450	3,810
LRG045	114.3	165.1	25.4	16	1.814	38,970	31,140	61,470	90,250	1,720	2,520	3,640
LRA047	120.7	133.4	6.35	60	0.104	6,760	3,380	10,280	9,880	260	250	4,000
LRB047	120.7	136.5	7.938	50	0.154	9,030	4,760	13,480	13,830	350	350	3,950
LRC047	120.7	139.7	9.525	41	0.227	10,940	6,090	16,060	17,660	420	460	3,900
LRD047	120.7	146.1	12.7	31	0.426	15,700	10,500	25,000	30,430	670	810	3,810
LRF047	120.7	158.8	19.05	22	0.998	27,620	19,170	41,010	55,560	1,150	1,550	3,640
